Description
Specificaties:
| Functie | Reeks | Resolutie | Nauwkeurigheid | MAX. Waarde | Opmerkingen |
| Gelijkstroomspanning (V) | 999.9mV | 0.1mV | ±(0,5%+3) | 999.9V | |
| 9.999V | 0.001V | ||||
| 99.99V | 0.01V | ||||
| 999.9V | 0.1V | ||||
| Gelijkstroomspanning (MV) | 9.999mV | 0.001mV | 99.99mV | ||
| 99.99mV | 0.01mV | ||||
| AC Spanning (V) | 999.9mV | 0.1mV | ±(1,0%+3) | 750V | 40Hz-1kHz |
| 9.999V | 0.001V | ||||
| 99.99V | 0.01V | ||||
| 750.0V | 0.1V | ||||
| AC Spanning (MV) | 9.999mV | 0.001mV | 99.99mV | ||
| 99.99mV | 0.01mV | ||||
| DC Stroom (mA & A) | 999.9mA | 0.1mA | ±(1,0%+3) | 9.999A | |
| 9.999A | 0.001A | ||||
| DC Stroom (μA) | 99.99μA | 0.01μA | ±(0,8%+3) | 999.9μA | |
| 999.9μA | 0.1μA | ||||
| AC Stroom (mA & A) | 999.9mA | 0.1mA | ±(1,2%+3) | 9.999A | 40Hz-1kHz |
| 9.999A | 0.001A | ||||
| AC Stroom (μA) | 99.99μA | 0.01μA | ±(1,0%+3) | 999.9μA | |
| 999.9μA | 0.1μA | ||||
| Weerstand | 99.99Ω | 0.01Ω | ±(1,0%+3) | 99.99MΩ | |
| 999.9Ω | 0.1Ω | ±(0,5%+3) | |||
| 9.999kΩ | 0.001kΩ | ||||
| 99.99kΩ | 0.01kΩ | ||||
| 999.9kΩ | 0.1kΩ | ||||
| 9.999MΩ | 0.001MΩ | ±(1,5%+3) | |||
| 99.99MΩ | 0.01MΩ |
| Functie | Reeks | Resolutie | Nauwkeurigheid | MAX. Waarde | Opmerkingen |
| Capaciteit | 9.999nF | 0.001nF | 9.999mF | ||
| 99.99nF | 0.01nF | ±(2,0%+5) | |||
| 999.9nF | 0.1nF | ||||
| 9.999μF | 0.001μF | ||||
| 99.99μF | 0.01μF | ||||
| 999.9μF | 0.1μF | ||||
| 9.999mF | 0.001mF | ±(5,0%+5) | |||
| Frequentie | 99.99Hz | 0.01Hz | 9.999MHz | ||
| 999.9Hz | 0.1Hz | ||||
| 9.999kHz | 0.001kHz | ||||
| 99.99kHz | 0.01kHz | ||||
| 999.9kHz | 0.1kHz | ||||
| 9.999MHz | 0.001MHz | ||||
| Arbeidscyclus | 1%~99% | 0,1% | ±(0,1%+2) | ||
| Diode | √ | ||||
| Continuïteit | √ | ||||
| NCV | √ | ||||
| Temperatuur | -20~1000℃ | 1℃ | ±(2,5%+5) | 1000℃ | |
| -4~1832℉ | 1℉ | ||||
| 1832℉ | |||||
| Algemene specificaties | |||||
| LCD scherm | 9999 Counts | ||||
| Variërend | 0~9999 |
